Product number:

30303 R

Brand:

Product name:

kúpgörg.csapágy

Sizes:

17X47X15.25

Catalog:

Catalog #1: http://www.rolling.hu/pdf/KOYO/30303R.pdf

Replacements:

30303*KOYO

Product details from catalogue:

d	17 mm
D	47 mm
T	15.25 mm
B	14 mm
C	12 mm
r(min.)	1 mm
r1(min.)	1 mm
Basic load ratings : Cr	34.2 kN
Basic load ratings : C0r	24.5 kN
Fatigue load limit : Cu	3.45 kN
Limiting speeds(Grease lub.)	9200 min-1
Limiting speeds(Oil lub.)	12000 min-1
Load center spread : a	10.5 mm
Constant e	0.28
Axial load factors : Y1	2.11
Axial load factors : Y0	1.16
da(min.)	22.5 mm
db(max.)	25 mm
Da(max.)	41.5 mm
da(min.)	40 mm
db(min.)	42 mm
Sa(min.)	2 mm
Sb(min.)	3 mm
ra(max.)	1 mm
rb(max.)	1 mm
(Refer.)Mass	0.127 kg
