Product number:

32310 JR

Brand:

Product name:

kúpgörg.csapágy

Sizes:

50X110X42,25

Suffixes:

A - Eltérõ furat, görgõ, rádiusz vagy palástátmérõ.

Catalog #2: 32310JR.pdf

Replacements:

VKHB 2299 32310 A SET 1079 VKHB 2303 VKHB 2401 S BT1 0510 HDB 009 57249 VKHB 2070 32310R VKBA 5038 ONLY BEARING 1

Product details from catalogue:

d	50 mm
D	110 mm
T	42.25 mm
B	40 mm
C	33 mm
r(min.)	2.5 mm
r1(min.)	2 mm
Basic load ratings : Cr	221 kN
Basic load ratings : C0r	220 kN
Fatigue load limit : Cu	34.2 kN
Limiting speeds(Grease lub.)	3700 min-1
Limiting speeds(Oil lub.)	5000 min-1
Load center spread : a	29.4 mm
Constant e	0.35
Axial load factors : Y1	1.74
Axial load factors : Y0	0.96
da(min.)	62 mm
db(max.)	62 mm
Da(max.)	98 mm
Da(min.)	90 mm
Db(min.)	102 mm
Sa(min.)	3 mm
Sb(min.)	9 mm
ra(max.)	2 mm
rb(max.)	2 mm
(Refer.)Mass	1.89 kg
