Product number:

32915 JR

Brand:

Product name:

kúpgörg.csapágy

Sizes:

75X105X20

Suffixes:

J - acélkosár (Pressed steel cage)

R. - Erõsített kivitel

Replacements:

32915 JR N HR 32915 J 4T-32915

Product details from catalogue:

d	75 mm
D	105 mm
T	20 mm
B	20 mm
C	16 mm
r(min.)	1 mm
r1(min.)	1 mm
Basic load ratings : Cr	92.2 kN
Basic load ratings : C0r	123 kN
Fatigue load limit : Cu	18.4 kN
Limiting speeds(Grease lub.)	3300 min-1
Limiting speeds(Oil lub.)	4400 min-1
Load center spread : a	18.9 mm
Constant e	0.33
Axial load factors : Y1	1.80
Axial load factors : Y0	0.99
da(min.)	80.5 mm
db(max.)	81 mm
Da(max.)	99.5 mm
Da(min.)	96 mm
Db(min.)	101 mm
Sa(min.)	4 mm
Sb(min.)	4 mm
ra(max.)	1 mm
rb(max.)	1 mm
(Refer.)Mass	0.526 kg
